Waukesha Cherry-Burrell
®
Brand Universal 3 Pump Parts List
11/2018 95-03103 Page 107
030, 040-U3 Parts
Notes:
* Recommended spare parts
1. Contact customer service with Serial Number of pump for Part Number.
2. Standard clearances and finishes for rotor part numbers shown. Contact customer service for optional clearances and
finishes. All rotors include rotor drive pins installed. For replacement pin, see item 9A (not shown).
4. The oil plug requires O-ring N70114.
41. Tru-Fit drive shaft is longer than the standard drive shaft listed here. See page 132.
43. Exposed length of dowel pin: .444" (11.3 mm)
44. Exposed length of dowel pin: .563" (14.3 mm)
For standard seals, see page 123. For specialty seals, see page 124. For standard seal kits, see page 127.
ITEM NO. DESCRIPTION
QTY.
PER
PUMP
PART NO. NOTES
1
Pump Body 1 See Note 1 1
030-U3 Pump Cover 1 133424+
040-U3 Pump Cover 1 137948+
3
Gear Case, SS, Model 030, 040 1 138122+
4
Gear Case Cover, SS 1 102281+
5
Gear, Drive Shaft, Spur 1 107999+
6
Gear, Short Shaft, Spur 1 107999+
7
030-040-U3 Drive Shaft 1 133419+ 41
8
030-040-U3 Short Shaft 1 133420+ 41
030-U3 Rotor, Twin Wing, Alloy 88 2 133421+ 2
030-U3 Rotor, Twin Wing, 316SS 2 137963+ 2
040-U3 Rotor, Twin Wing, Alloy 88 2 137966+ 2
040-U3 Rotor, Twin Wing, 316SS 2 137972+ 2
9
A
Rotor drive pin (not shown) 2 137985+ 2
030-U3 Stud 8 109865+
040-U3 Stud 8 138604+
11
Hex Nut 8 108370+
12
Oil Seal, Gear Case Cover 1 000030013+
13
Oil Seal, Gear Case Rear 2 000030014+
14
Grease Seal, Bearing Retainer 2 121680+
15
Bearing, Rear 2 030035000+
16
Bearing, Front 2 101715+
17
Key, Gear 2 BD0037000
20
Dowel Pin, Cover Side, .245" x .85" 1 137001+ 43
21
Dowel Pin, Gear Case Side, .308" x 1.0" 1 124582+ 44
22
Dowel Pin, Cover Side, .308" x .85" 1 137002+ 43
23
Dowel Pin, Gear Case Side, .370" x 1.0" 1 124583+ 44
Oil Plug, M20 x 1.5"
5 137169+
* O-Rin
g
, Buna
(
for oil plu
g)
5 N70114
Oil Level Indicator, M20 x 1.5" 1 137435+
25
Silicone Sealant 1 000142301+
26
Nut, Rotor 2 137947+
O-Ring, Rotor Nut, EPDM 2 E70126
*
O-Ring, Rotor Nut, FKM 2 V70126
O-Ring, Rotor Nut, FFKM 2 K70126
PL5060-CH154
26A
4
2
9
24
10
