SPX FLOW 030-U3 User Manual

Waukesha Cherry-Burrell
®
Brand Universal 3 Pump Parts List
11/2018 95-03103 Page 109
030, 040-U3 Parts
Notes:
* Recommended spare parts
For standard seals, see page 123. For specialty seals, see page 124. For standard seal kits, see page 127.
3. See “Replacement Labels” on page 12 for label detail.
ITEM NO. DESCRIPTION
QTY.
PER
PUMP
PART NO. NOTES
27
Shim Kit 2 117890+
29
Spacer, Gear to Rear Bearing 2 030055000+
30
Bearing Spacer 2 101815+
32
Bearing Retainer, Front 2 120333+
33
A
5/16-18 X 3/4" HHCS, SS 8 30-623
33B
5/16-18 X 3/4" SHCS, SS 8 30-296
33C
5/16" Flat Washer 8 43-246
34
Dowel Bushing, Upper 1 BD0116000
35
Dowel Bushing, Lower 1 BD0116100
030-040-U3 Cover Gasket, FKM 1 130296+
*
030-040-U3 Cover Gasket, FFKM 1 137240+
030-040-U3 Cover Gasket, EPDM 1 137245+
39
Lockwasher, Gear 2 CD0036W00
41
Locknut, Gear 2 CD0036N00
42
Mounting Foot 030-040-U3 SS 1 102285+
43
Plastic Cap Plug 6 000121002+
44
3/8-16 x 1" SHCS 4 30-189
030-U3 Body Retaining Screw 2 30-613
040-U3 Body Retaining Screw 2 30-740
46
Eye Bolt, 3/8-16 x 9/16" SS 2 30-720
Key, Coupling - 1/4 x 1/4 x 1-3/4" 1 000037002+
Key, Coupling - Tru-Fit 1 119715+
48
Cleanout Plug, SS 2 102297+
56
030-040-U3 Seal Guard 2 138897+
61
Name Plate, Sanitary 1 135624+
62
#2 x .187" RHDS 4 30-355
65
Caution Plate 2 121694+
66
Warning Label 2 33-63
67
Grease Fitting, 1/8" 4 LL118404
68
Plastic Cap, Grease Fitting 4 BD0093000
PL5060-CH155
47
36
45
