SPX FLOW 030-U3 User Manual

Waukesha Cherry-Burrell
®
Brand Universal 3 Pump Parts List
11/2018 95-03103 Page 111
045, 060, 130-U3 Parts
See notes on page 110.
ITEM NO. DESCRIPTION
QTY.
PER
PUMP
PART NO. NOTES
1
Pump Body 1 See Note 1 1
045-U3 Pump Cover 1 138049+
060-U3 Pump Cover 1 138048+
130-U3 Pump Cover 1 138031+
3
Gear Case, SS, Model 045, 060, 130 1 138131+
4
Gear Case Cover, SS 1 102282+
5
Gear, Drive Shaft, Spur 1 107404+
6
Gear, Short Shaft, Spur 1 107404+
7
045-060-130-U3 Drive Shaft 1 138042+ 41
8
045-060-130-U3 Short Shaft 1 138043+ 41
045-U3 Rotor, Twin Wing, Alloy 88 2 138035+ 2
045-U3 Rotor, Twin Wing, 316SS 2 138055+ 2
060-U3 Rotor, Twin Wing, Alloy 88 2 138036+ 2
060-U3 Rotor, Twin Wing, 316SS 2 138063+ 2
130-U3 Rotor, Twin Wing, Alloy 88 2 138037+ 2
130-U3 Rotor, Twin Wing, 316SS 2 138070+ 2
9
A
Rotor drive pin (not shown) 2 137985+ 2
045-U3 Stud 8 138611+
060-U3 Stud 8 108843+
130-U3 Stud 8 138612+
11
Hex Nut 8 108371+
12
Oil Seal, Gear Case Cover 1 000030012+
13
Oil Seal, Gear Case Rear 2 000030011+
14
Grease Seal, Bearing Retainer 2 101829+
15
Bearing, Rear 2 107186+
16
Bearing, Front 2 060036000+
17
Key, Gear 2 060037000+
20
Dowel Pin, Cover Side, .308" x .85" 1 137002+ 43
21
Dowel Pin, Gear Case Side, .433" x 1.0" 1 124584+ 44
22
Dowel Pin, Cover Side, .370" x .85" 1 137003+ 43
23
Dowel Pin, Gear Case Side, .495" x 1.0" 1 124586+ 44
Oil Plug, M20 x 1.5" 5 137169+ 4
*
O-Ring, Buna (for oil plug) 5 N70114
Oil Level Indicator, M20 x 1.5" 1 137435+
25
Silicone Sealant 1 000142301+
26
Nut, Rotor 2 138044+
O-Ring, Rotor Nut, EPDM 2 E70224
*
O-Ring, Rotor Nut, FKM 2 V70224
O-Ring, Rotor Nut, FFKM 2 K70224
PL5060-CH156
24
26A
2
9
10
