SPX FLOW 030-U3 User Manual

Waukesha Cherry-Burrell
®
Brand Universal 3 Pump Parts List
11/2018 95-03103 Page 113
045, 060, 130-U3 Parts
Notes:
* Recommended spare parts
For standard seals, see page 123. For specialty seals, see page 124. For standard seal kits, see page 128.
3. See “Replacement Labels” on page 12 for label detail.
ITEM NO. DESCRIPTION
QTY.
PER
PUMP
PART NO. NOTES
27
Shim Kit 2 117891+
29
Spacer, Gear to Rear Bearing 2 107187+
30
Bearing Spacer 2 060055003+
31
Retainer, Grease 2 STD091000
32
Bearing Retainer, Front 2 121828+
33
A
3/8-16 x 3/4" HHCS Gear Case Cover 8 30-50
33B
3/8-16 x 1-1/4" HHCS, SS Bearing Retainer 8 30-60
33C
3/8" Flat Washer, Gear Case Cover 8 43-30
34
Dowel Bushing, Upper 1 CD0116000
35
Dowel Bushing, Lower 1 CD0116100
045-060-130-U3 Cover Gasket, FKM 1 133633+
*
045-060-130-U3 Cover Gasket, FFKM 1 137241+
045-060-130-U3 Cover Gasket, EPDM 1 137246+
39
Lockwasher, Gear 2 STD136009
41
Locknut, Gear 2 STD236009
42
Mounting Foot 045-060-130-U3 SS 1 102286+
43
Plastic Cap Plug 6 000121001+
44
1/2-13 x 1-1/4" SS SHCS 4 30-503
045-U3 Body Retaining Screw 2 30-319
060-U3 Body Retaining Screw 2 30-760
130-U3 Body Retaining Screw 2 30-761
46
Eye Bolt, 1/2-13 x 3/4" 2 30-721
Key, Coupling - 3/8 x 3/8 x 1-5/8" 1 000037003+
Key, Coupling - Tru-Fit 1 119716+
48
Cleanout Plug, SS 2 102297+
56
045-060-130-U3 Seal Guard 2 138898+
61
Name Plate, Sanitary 1 135624+
62
#2 x .187" RHDS 4 30-355
65
Caution Plate 2 121694+
66
Warning Label 2 33-60
67
Grease Fitting, 1/8" 4 LL118404
68
Plastic Cap, Grease Fitting 4 BD0093000
PL5060-CH157
47
36
45
