SPX FLOW 030-U3 User Manual

Waukesha Cherry-Burrell
®
Brand Universal 3 Pump Parts List
11/2018 95-03103 Page 117
180, 220-U3 Parts
Notes:
* Recommended spare parts
For standard seals, see page 123. For specialty seals, see page 124. For standard seal kits, see page 128.
3. See “Replacement Labels” on page 12 for label detail.
ITEM NO. DESCRIPTION
QTY.
PER
PUMP
PART NO. NOTES
27
Shim Kit 2 117892+
29
Spacer, Gear to Rear Bearing 2 40878+
30
Bearing Spacer 2 40752+
32
Bearing Retainer, Front 2 121829+
33
A
3/8-16 x 1-1/4" HHCS, SS Gear Case Cover 6 30-60
33B
3/8-16 x 1-1/4" HHCS, SS Bearing Retainer 8 30-60
33C
3/8" Flat Washer, Gear Case Cover 6 43-30
34
Dowel Bushing, Upper 1 CD0116000
35
Dowel Bushing, Lower 1 CD0116100
180-220-U3 Cover Gasket, EPDM 1 137433+
*
180-220-U3 Cover Gasket, FKM 1 137431+
180-220-U3 Cover Gasket, FFKM 1 137432+
39
Lockwasher, Gear 2 STD136011
41
Locknut, Gear 2 STD236011
42
Mounting Foot 180-220-U3 SS 1 102287+
43
Plastic Cap Plug 6 000121001+
44
1/2-13 x 1-1/4" SS SHCS 4 30-503
180-U3 Body Retaining Screw 2 30-766
220-U3 Body Retaining Screw 2 30-717
46
Eye Bolt, 1/2-13 x 3/4" 2 30-721
Key, Coupling - 1/2 x 1/2 x 1-7/8" 1 000037004+
Key, Coupling - Tru-Fit 1 119717+
48
Cleanout Plug, SS 2 102297+
56
180-220-U3 Seal Guard 2 138899+
61
Name Plate, Sanitary 1 135624+
62
#2 x .187" RHDS 4 30-355
65
Caution Plate 2 121694+
66
Warning Label 2 33-60
67
Grease Fitting, 1/8" 4 LL118404
68
Plastic Cap, Grease Fitting 4 BD0093000
PL5060-CH159
47
36
45
