SPX FLOW 030-U3 User Manual

Waukesha Cherry-Burrell
®
Brand Universal 3 Pump Parts List
11/2018 95-03103 Page 119
210, 320-U3 Parts
Notes:
* Recommended spare parts
1. Contact customer service with Serial Number of pump for Part Number.
2. Standard clearances and finishes for rotor part numbers shown. Contact customer service for optional clearances and
finishes. All rotors include rotor drive pins installed. For replacement pin, see item 9A (not shown).
4. The oil plug requires O-ring N70114.
41. Tru-Fit drive shaft is longer than the standard drive shaft listed here. See page 132.
43. Exposed length of dowel pin: .75" (19 mm)
44. Exposed length of dowel pin: 1.125" (28.6 mm)
For standard seals, see page 123. For specialty seals, see page 124. For standard seal kits, see page 129.
ITEM NO. DESCRIPTION
QTY.
PER
PUMP
PART NO. NOTES
210-U3 Stud, Long 4 138340+
320-U3 Stud, Long 4 138341+
10
A
210-320-U3 Stud, Short 4 111292+
11
Hex Nut 8 108373+
12
Oil Seal, Gear Case Cover 1 STD030004
13
Oil Seal, Gear Case Rear 2 102475+
14
Grease Seal, Bearing Retainer 2 121681+
15
Bearing, Rear 2 0H1036000
16
Bearing, Front 2 0H1036003
17
Key, Gear 2 0H1037000
20
Dowel Pins, Cover Side 2 0H1040000 43
21
Dowel Pins, Gear Case Side 2 105871+ 44
Oil Plug, M20 x 1.5" 5 137169+
* O-Rin
g
, Buna
(
for oil plu
g)
5 N70114
Oil Level Indicator, M20 x 1.5" 1 137435+
25
Silicone Sealant 1 000142301+
26
Nut, Rotor 2 138288+
O-Ring, Rotor Nut, EPDM 2 E70231
*
O-Ring, Rotor Nut, FKM 2 V70231
O-Ring, Rotor Nut, FFKM 2 K70231
27
Shim Kit 2 117893+
28
Shim Plate 2 134506+
Shims, Body, .002 AR 134507+
Shims, Body, .003 AR 134508+
Shims, Body, .005 AR 134509+
Shims, Body, .010 AR 134510+
Shims, Body, .020 AR 134511+
28D
5/16-18 x 1" FHSCS 4 30-612
29
Spacer, Gear to Rear Bearing 2 102474+
30
Bearing Spacer 2 102472+
30
A
Spacer Seal 2 102473+
31
Retainer, Grease 2 STD091000
32
Bearing Retainer, Front 2 123533+
33
A
3/8-16 x .75" HHCS 6 30-50
33B
5/16-18 x 1.125" BSHCS 8 30-742
33C
3/8" Flat Washer 6 43-30
34
Dowel Bushings 2 0H1116000
PL5060-CH160a
4
24
26A
28A
10
