Matrix Owner’s Manual
100
Appendix B - Technical Specifications
M
M
a
a
t
t
r
r
i
i
x
x
D
D
i
i
g
g
i
i
t
t
a
a
l
l
I
I
O
O
S
S
p
p
e
e
c
c
i
i
f
f
i
i
c
c
a
a
t
t
i
i
o
o
n
n
s
s
Test conditions (unless otherwise specified): Input test signal is a 1 kHz sine wave; measurement bandwidth is 22Hz to 22kHz,
signal level is –1dBFs.
Stereo ADC
S
ource selectable between Mix bus, Record bus and Monitor (pre level control) signals.
Connections: S/PDIF (TosLink optical) and AES-3 (male XLR). Signal available on both connectors at all times.
Sample rate – locks to selected digital input up to a maximum sample rate of 176.4kHz. In the absence of a valid digital input
d
efaults to 44.1kHz.
Dynamic range typically 113dB A-weighted, 111dB unweighted. Worst case 108dB unweighted
THD < 0.0015%
0dBFs switchable between +18dBu and +24dBu
DAC
Connections: source selectable from Matrix front panel between S/PDIF (TosLink optical) and AES-3 (female XLR) inputs.
Sample rate 32kHz to 176.4kHz
Dynamic range typically 116dB A-weighted, 111dB unweighted. Worst case 109dB unweighted
THD < 0.001%
0dBFs switchable between +18dBu and +24dBu
