Ssl Matrix - TR Soft Keys; IP Soft Keys; Misc Soft Keys

T
T
R
R
S
S
o
o
f
f
t
t
K
K
e
e
y
y
s
s
The
TTRR
soft keys allow Matrix’s Total Recall functions to be controlled from the console:
T
otal Recall is described on Page 53.
EEnnaabbllee
enables TR for restoring snapshots.
TTaakkeeTTRR
takes a TR snapshot.
SSeettSSeell
sets a TR snapshot to any channels selected using the upper SEL key.
SSeettAAllll
sets a TR to the whole console.
CCuurr::
displays the TR number which is currently selected in the Total Recall tab of the Matrix Remote.
I
I
P
P
S
S
o
o
f
f
t
t
K
K
e
e
y
y
s
s
The
IIPP
soft keys allow you to switch the console’s IP address between
FFiixxeedd
and
DDHHCCPP
.
The IP address information is shown after the
DDHHCCPP
button. By default, Matrix uses a fixed IP address of 192.168.1.2. with the
subnet mask set to 255.255.255.0.
See Page 5 for a description of how to change the fixed IP address.
See Page 4 for details of configuring the console’s Ethernet connectivity.
M
M
i
i
s
s
c
c
S
S
o
o
f
f
t
t
K
K
e
e
y
y
s
s
The
MMiisscc
soft keys cover miscellaneous Matrix settings:
IInnppCCuu
configures the channel CUT buttons. By default, pressing the channel CUT button mutes the channel output, leaving
any pre-fader feeds from the channel unaffected. Pressing
IInnppCCuu
causes the CUT buttons to mute the channel after the input,
muting any feeds from the channel that are not sourced from the INPUT.
OOppttDDAACC
switches between the two digital inputs. By default, the AES (XLR) input is selected. Pressing the
OOppttDDAACC
button
selects the S/PDIF input, and the button lights to indicate that this input has been selected.
Fader Options:
MMsstt++1100
rescales the master fader. By default, the master fader reaches 0dB at the top, following the scaling labelled on the
left of the fader. Pressing
MMsstt++1100
switches the meter’s scaling to reach +10dB at the top, following the labelling on the right
of the fader.
00ddBB
and
OOffff
move the analogue faders on any channels selected using the upper SEL key to 0dB and -
∞∞
respectively.
Meter Signal Scale Option:
The default scale for all of the LED meters is meters is 0dBfs corresponds to an analogue level of +24dBu. The
++1188ddBB
button
provides an alternative scaling of +18dBu.
USB Keyboard Identifier:
The
KKeeyybbIIDD
key is used to identify the nationality of keyboard being emulated by the Matrix USB soft keys. See Page 86 for
details.
