X-Rack / Diag
Location: Matrix rear panel
Connector Type: 9-way D-type female
Pin Description Notes:
1 -
6 -
2 Tx Data X-Rack data out
7 (Tx Data) (diagnostic terminal data out)
3 Rx Data X-Rack data in
8 -
4 (Rx Data) (diagnostic terminal data in)
9 -
5 0V data ground
Matrix 25-way D pinouts
Location: Matrix rear panel
Connector Type: 25-way D-type female
Circuit hot cold screen
Rec,Mix,Cue Send Rec,Mix,Cue Rtn Cue St,FX1-4 Snd FX1-4 Rtn
1 24 12 25 Rec Send L Rec Return L Cue Out L FX return 1L
2 10 23 11 Rec Send R Rec Return R Cue Out R FX return 1R
3 21 9 22 Mix Send L Mix Return L FX 1 Out FX return 2L
4 7 20 8 Mix Send R Mix Return R FX 2 Out FX return 2R
5 18 6 19 Cue Send L Cue Return L FX 3 Out FX return 3L
6 4 17 5 Cue Send R Cue Return R FX 4 Out FX return 3R
7 15 3 16 - - - FX return 4L
8 1 14 2 - - - FX return 4R
Matrix 25-way D pinouts
Location: Matrix rear panel
Connector Type: 25-way D-type female
Circuit hot cold screen
Channels 1–8, 9–16 Ext 1,2 Mon LS Artist out Rec, Mix F/Mon
1 24 12 25 Channel 1 (9) Ext 1 Input L Mon Out L Rec Out L
2 10 23 11 Channel 2 (10) Ext 1 Input R Mon Out R Rec Out R
3 21 9 22 Channel 3 (11) Ext 2 Input L Mini Out L Mix Out L
4 7 20 8 Channel 4 (12) Ext 2 Input R Mini Out R Mix Out R
5 18 6 19 Channel 5 (13) - Artist Out L Follow Mon Out L
6 4 17 5 Channel 6 (14) - Artist Out R Follow Mon Out R
7 15 3 16 Channel 7 (15) - - -
8 1 14 2 Channel 8 (16) - - -
Appendix C - Pinouts
104
Matrix Owner’s Manual
