Starlite MK5 - Electrical Specifications; Unit Electrical Data; Replacement Lamp and Fuse Information

STARLITE Mk5 User Manual Version 1.2
19
Specifications (Electrical)
Unit
Type
Voltage
Range
Frequency
Range
Current
Consumption
(@ 230 V/50 Hz)
Power
Consumption
(@ 230 V/50 Hz)
575 W
Magnetic
Ballast
200-250 V 50 / 60 3.2 A 0.75 kW
575 W
Electronic
Ballast
95-130 / 200-250 47 - 65 4.4 A 1.0 kW
1200 W
Magnetic
Ballast
200-250 V 50 / 60 7.2 A 1.7 kW
1200 W
Electronic
Ballast
95-130 / 200-250 47 - 65 6.7 A 1.5 kW
Replacement Lamp Type:
575 W models 575 W/GS HMI Lamp, Osram  (or equivalent)
1200 W models 1200 W/GS HMI Lamp, “ “
Please Note: Certain types of HMI Lamps will not work with the different ballast/ignitor
combinations available in this unit, due to the manufacturer’s varying gas/rare earth mixtures.
Please consult your distributor/Starlite for advice.
Replacement Fuses
FUNCTION FUSE RATING FUSE SIZE
Fans, +5 volts 2 Amp (T) 250 V 20mm or 32mm (1¼”)
volt select switch 3.15 Amp (T) 250 V 20mm
pan/tilt motors 2.5 Amp (T) 250 V 20mm or 32mm (1¼”)
24 V stepper drive 6.3 Amp (T) 250 V 20mm or 32mm (1¼”)
12 V stepper drive 10 Amp (T) 250 V 20mm or 32mm (1¼”)
PLEASE NOTE: Replacement fuses must be of the “T” type (i.e. time delay/slow blow)
and of the correct voltage/current rating.
Replacement fuses are available from your distributor/Starlite.
