STARLITE Mk5 User Manual Version 1.2
22
Factory Set Personality
The Starlite Mk 5 is despatched with the default personality set (as described below) but this can be
altered to any other personality, if the user wishes. This feature is extremely useful when the Starlite
Mk 5 is being used along with, or takes the place of, other makes of moving lights. The Starlites can
be configured to the personality required, there by reducing programming time.
(See: Setting the Personality and Address DIP Switches)
Default Channel Configuration (“Personality”)
DMX
CHANNEL
NO.
UNIT FUNCTION DMX
VALUE
CHANNEL
VALUE
(1-100%)
SPEED
CHANNEL
ENABLED
(CH. 19)
NOTES
1
2
Pan (Hi-Byte)
Pan (Low-Byte)
0-255
0-255
0-100%
0-100%
Normally combined
in the control desk.
3
4
Tilt (Hi-Byte)
Pan (Low-Byte)
0-255
0-255
0-100%
0-100%
Normally combined
in the control desk.
5 Colour Wheel
Open White
Bump to Colour 1 (Blue 107)
Bump to Colour 2 (Green 206)
Bump to Colour 3 (Red 301)
Bump to Colour 4 (Orange CTC)
Bump to Colour 5 (Blue CTC)
Open White
Scroll to Colour 1 (Blue 107)
Scroll to Colour 2 (Green 206)
Scroll to Colour 3 (Red 301)
Scroll to Colour 4 (Orange CTC)
Scroll to Colour 5 (Blue CTC)
Continuous Colour Scroll (Slow)
“ “ “
“ “ “
“ “ “
Continuous Colour Scroll (Fast)
0
8
16
24
32
40
64
72
80
88
96
104
128
255
0%
3%
6%
9%
13%
16%
25%
28%
31%
34%
38%
41%
50%
100%
Yes
Yes
Yes
Yes
Yes
Yes
6 Cyan
Open
Cyan
Closed (Full Cyan Colour)
0
255
0%
100%
7 Magenta
Open
Magenta
Closed(Full Magenta Colour)
0
255
0%
100%
8 Yellow
Open
Yellow
Closed(Full Yellow Colour)
0
255
0%
100%
