STARLITE Mk5 User Manual Version 1.2
23
DMX
CHANNEL
NO.
UNIT FUNCTION
DMX
VALUE
CHANNEL
VALUE
(1-100%)
SPEED
CHANNEL
ENABLED
(CH. 19)
NOTES
9 Gobo Rotate Wheel 1
Stop
Rotate (Fast) CW
“ CW
Rotate (Slow) CW
Stop
Rotate (Slow) CCW
“ CCW
Rotate(Fast) CCW
Registration 0°
“
“
“
Registration 360°
0
4
120
127
134
255
0
255
0%
1.5%
47%
49.5%
52.5%
100%
0%
100%
When Channel 10,
Gobo Select (1), is
between the values of
0 - 127
(DMX)
0 - 49.5% (Channel)
When Channel 10,
Gobo Select (1), is
between the values of
128-255 (DMX)
50-100% (Channel)
10
Gobo Select Wheel 1
Open White
Bump Change Gobo “Rotation” 1
Bump Change Gobo “Rotation” 2
Bump Change Gobo “Rotation” 3
Bump Change Gobo “Rotation” 4
Bump Change Gobo “Rotation” 5
Open White
Scroll Change Gobo “Rotation” 1
Scroll Change Gobo “Rotation” 2
Scroll Change Gobo “Rotation” 3
Scroll Change Gobo “Rotation” 4
Scroll Change Gobo “Rotation” 5
Open White
Bump Change Gobo “Indexing” 1
Bump Change Gobo “Indexing” 2
Bump Change Gobo “Indexing” 3
Bump Change Gobo “Indexing” 4
Bump Change Gobo “Indexing” 5
Open White
Scroll Change Gobo “Indexing” 1
Scroll Change Gobo “Indexing” 2
Scroll Change Gobo “Indexing” 3
Scroll Change Gobo “Indexing” 4
Scroll Change Gobo “Indexing” 5
0
8
16
24
32
40
64
72
80
88
96
104
128
136
144
152
160
168
192
200
208
216
224
232
0%
3%
6%
9%
13%
16%
25%
28%
31%
34%
38%
41%
50%
53%
56%
59%
63%
66%
75%
78%
81%
84%
88%
91%
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
