Steris 4085 - Page 153

S
V
C
DESCRIPTION
22
764333-767
FIG. &
ITEM
NO.
PART
NUMBER
UNITS PER
ASSEMBLY
3 4085 Surgical Tabletop Slide and Section Assemblies................ X
1 342273 555 ASSEMBLY, Leg Section, Locking Device........................................... 2
2 542200 029 • KEY, Lock .......................................................................................... 2
3 632500 055 • SPRING, Compression, 8 x 16mm .................................................... 2
4 542200 221 ASSEMBLY, Cable, Switch/Leg Section .............................................. 1
5 600020 208 SCREW, TC M2 x 10 ........................................................................... 2
6 542200 030 COVER, Leg Switch Plate.................................................................... 2
7 600410 412 SCREW, Flat Head, M4 x 12 SS.......................................................... 3
8 P 755718 045 SUBASSEMBLY, Leg Cylinder, With Hoses, Right Leg....................... 1
P 755718 046 SUBASSEMBLY, Leg Cylinder, With Hoses, Left Leg......................... 1
** • CYLINDER......................................................................................... 1
* • SCREW, Hydraulic, Single Way ........................................................ 2
* • WASHER, Sealing ............................................................................ 4
9 688200 019 SENSOR, Trendelenburg/Tilt .............................................................. 2
10 P 764333 536 PACK, Switch Kidney ........................................................................... 1
11 542200 220 • SWITCH............................................................................................. 1
12 600020 210 • SCREW, TC, M2 x 10 ........................................................................ 1
13 P 755718 043 SUBASSEMBLY, Kidney Cylinder, With Hoses, Right......................... 1
P 755718 044 SUBASSEMBLY, Kidney Cylinder, With Hoses, Left........................... 1
** • CYLINDER, Kidney ........................................................................... 1
* • SCREW, Small Hydraulic, Single Way .............................................. 2
* • WASHER, Small Sealing ................................................................... 4
14 342242 555 SENSOR, Back Section ....................................................................... 1
15 542200 090 • SENSOR ............................................................................................ 1
16 600530 410 • SCREW, Socket Head Cap, M4 x 10................................................. 2
17 P 755718 047 SUBASSEMBLY, Back Cylinder, With Hoses, Back Right................... 1
P 755718 048 SUBASSEMBLY, Back Cylinder, With Hoses, Back Left..................... 1
** • CYLINDER......................................................................................... 1
* • SCREW, Hydraulic, Single Way ........................................................ 2
* • WASHER, Sealing ............................................................................. 4
18 P 755717 985 MEMBER, Right Back Section ............................................................. 1
19 P 755717 984 MEMBER, Left Back Section................................................................ 1
20 P 077559 056 ASSEMBLY, Knob................................................................................ 2
21 600610 408 SETSCREW, Cup Point, M4 x 8 .......................................................... 2
22 600780 408 SCREW, Socket Head Cap, M4 x 8 SS ............................................... 10
23 P 150832 592 ASSEMBLY, Sliding Power Control ..................................................... 1
24 600990 031 SCREW, Button Head, M6 x 16 SS (Not Shown) ................................ 8
25 600530 510 SCREW, Socket Head Cap, M5 x 10 ................................................... 6
26 542200 025 SENSOR .............................................................................................. 1
27 600410 410 SCREW, M4 x 10 ................................................................................. 1
28 542200 085 PLATE, Switch ..................................................................................... 1
29 542200 196 SENSOR, Sliding ................................................................................. 1
30 600410 306 SCREW, Fillester Head Cap, M3 x 6 SS ............................................. 4
31 P 150832 734 CARRIER, Translation Wire ................................................................ 2
