Steris 4085 - Page 154

S
V
C
DESCRIPTION
23
764333-767
FIG. &
ITEM
NO.
PART
NUMBER
UNITS PER
ASSEMBLY
3 4085 Surgical Tabletop Slide and Section Assemblies................. X
HEAD AND LEG SECTIONS
32 ASSEMBLY, Leg Section (See Figure 8)............................................. 1
33 TOP SECTION AND RAILS (See Figure 2; Headrest, See Figure 7)
34 COVERS, LEG SECTION (See Figure 2)
35 542200 270 PROTECTOR, Articulator, #5 .............................................................. 2
36 542200 392 ASSEMBLY, Cable Guide Support (For The Slide Sensor Cable) ...... 1
37 605300 004 • SHEAVE, Cable Guide ...................................................................... 1
38 600530 508 SCREW, Socket Head Cap, M5 x 8 SS .............................................. 1
39 342231 555 SUBASSEMBLY, Sliding Motor ........................................................... 1
40 699500 017 • MOTOR, 24V 26W ............................................................................ 1
41 542200 186 • GEAR, Pinion .................................................................................... 1
42 639409 301 • RING, Retaining ................................................................................ 1
43 542200 046 PLATE, Motor Housing ........................................................................ 1
44 600410 616 SCREW, Flat Head Cap, M6 x 16 SS.................................................. 3
45 688100 015 SUPPRESSOR, Voltage (Diode)......................................................... 1
46 542200 173 BRACKET, Left Seat Cover Support ................................................... 1
47 542200 174 BRACKET, Right Seat Cover Support................................................. 1
48 P 150832 118 GRIP, Cable Right ............................................................................... 1
49 542200 082 GRIP, Cable Left.................................................................................. 1
50 600990 077 SCREW, Button Head, M4 x 10........................................................... 3
51 542200 195 LINEAR Bearing, With Rail .................................................................. 4
52 P 090348 061 ROLLPIN.............................................................................................. 2
53 P 093909 431 BEARING, Headrest ............................................................................ 2
54 542200 031 SHAFT, Rear Guide............................................................................. 2
55 600660 812 SETSCREW, Flat Point, M8 x 12, Steel Black Oxide .......................... 2
56 542200 020 CLEVIS, Machined............................................................................... 4
57 P 150832 119 ASSEMBLY, Rod Link ........................................................................ 2
58 542200 028 ASSEMBLY, Left Leg End ................................................................... 1
59 542200 026 ASSEMBLY, Right Leg End................................................................. 1
60 542200 021 SHAFT, Clevis ..................................................................................... 2
61 542200 022 BEARING, Guide ................................................................................. 4
62 542200 027 SHAFT ................................................................................................. 7
63 600610 505 SETSCREW, M5 x 5............................................................................ 7
64 P 150832 247 BRACKET, Sensor Reader Mounting, Leg Section............................. 1
65 542200 073 BRACKET, Kidney Cylinder................................................................. 2
66 600410 510 SCREW, Flat Head Cap, Hex Socket, M5 x 10, SS ............................ 2
67 542200 083 ROD, Center Primary........................................................................... 2
68 542200 084 ROD, Center Secondary...................................................................... 2
69 600660 608 SETSCREW, Flat Point, M6 x 8, Steel Black Oxide ............................ 4
70 P 755718 075 ASSEMBLY, Kidney Bridge Linkage, Patient Right............................. 1
71 P 755718 076 ASSEMBLY, Kidney Bridge Linkage, Patient Left ............................... 1
72 542200 086 SLIDE, Machined Cylinder................................................................... 4
73 P 150832 248 BRACKET, Back Section Sensor Reader Mounting ............................ 1
74 542200 398 GUIDE, Back Section Cable/Hose....................................................... 2
75 R 005300 554 LOCTITE #242..................................................................................... A/R
