Steris 4085 - Page 158

S
V
C
DESCRIPTION
28
764333-767
FIG. &
ITEM
NO.
PART
NUMBER
UNITS PER
ASSEMBLY
4 4085 Table Base Assemby With Plastic Shrouds ........................ X
4085 Table Base Assemby With SS Shrouds................................ X
1 WELDMENT, Base (Not Service Component) ..................................... 1 1
2 P 764332 718 PACK, Casters (Set of Four) ................................................................ A/R A/R
P 150832 207 • CASTER ............................................................................................ 4 4
3 P 150832 187 • WASHER, Flat, 1/2, SS...................................................................... 4 4
4 602183 212 • LOCKWASHER, M12, SS.................................................................. 4 4
5 601381 206 • NUT, Hex, M12 x 1.75, SS................................................................. 4 4
6 342228 555 ASSEMBLY, Main Valve Block ............................................................ 1 1
7 602601 016 LOCKWASHER, M10, SS .................................................................... 7 7
8 601321 080 NUT, Hex, M10 x 1.5, SS ..................................................................... 7 7
9 542200 192 LABEL, Base Illumination..................................................................... 1 1
10 063022 LABEL, Service .................................................................................... 1 11
11 542200 902 SUPPLY, Power, 120V......................................................................... 1 1
542201 902 SUPPLY, Power, 220V ........................................................................ A/R A/R
12 P 764332 972 • MODULE, Power Entry (AC Receptacle and Switch) ........................ 1 1
P 764333 768 DRAWER, Fuse (Power Supply/Module)............................................. 1 1
13 600530 616 SCREW, Socket Head Cap, M6 x 16mm, SS ...................................... 2 2
14 602181 862 WASHER, Fender, M6 ......................................................................... 5 5
15 P 129360 371 PLUG, International Ground................................................................. 1 1
16 542200 331 PLATE, Fuse Cover ............................................................................. 1 1
17 413724 348 LABEL, Fuse Cover Plate .................................................................... 1 1
18 600410 410 SCREW, Fillester Head, Hex, M4 x 10mm, SS.................................... 1 1
19 651900 006 BUMPER, Hemisphere, 19mm Dia ...................................................... 3 3
20 542200 415 LABEL, Battery..................................................................................... 1 1
21 342211 555 ASSEMBLY, Hydraulic Pump .............................................................. 1 1
542200 414 • LABEL, Oil Level................................................................................ 1 1
P 764322 636 • OIL, Hydraulic ................................................................................... 1 1
22 P 026962 061 LOCKWASHER, 1/4, Internal Tooth..................................................... 3 3
23 P 462338 710 TERMINAL, Insulated Ring, 1/4, 2218 Ga ........................................... 2 2
24 600530 608 SCREW, Shoulder Head Cap, M6 x 8mm, SS..................................... 5 5
25 P 129360 483 LABEL, Natural Ground........................................................................ 2 2
26 542200 455 BRACKET, Battery Holding.................................................................. 1 1
27 600530 510 SCREW, Socket Head Cap, M5 x 10mm, SS ...................................... 4 4
28 P 764331 223 BATTERY, 12V (Set of Two)................................................................ 1 1
29 P 150832 490 CABLE, Fuse/Battery/Charger ............................................................. 1 1
P 764333 102 • HOLDER, Fuse.................................................................................. 1 1
693600 041 • FUSE, 16A......................................................................................... 1 1
30 P 150832 491 • WASHER, Special Flat....................................................................... 2 2
31 P 755717 725 PUMP, 4085 Hydraulics Foot ............................................................... 1 1
P 764332 977 • YOKE, Foot Pump ............................................................................. 1 1
32 P 755717 718 PACK, Floor Lock Cylinder Parts (Set of Four) .................................... A/R A/R
P 755717 717 • CYLINDER, Floor Lock...................................................................... 4 4
342215 555 SUBASSEMBLY, Foot Cylinder........................................................... – 4
33 P 150832 288 MOUNT, Leveling................................................................................. 4 4
34 600530 625 SCREW, Shoulder Head Cap, M6 x 25mm, SS................................... 12 12
