Steris 4085 - 6- 4085 Electrical Cables

37
764333-767
Fig/
Item/
Hose
Position
Part Number Description
Cable
Postition
From
Cable Position To
Q
T
Y
6- 4085 Electrical Cables X
1 P 150832 632 HAND CONTROL ASSEMBLY (Without
Cable)
P30 1
2 542200 420 CABLE/CORD, Hand Control Coil P1 P30, Hand Controller 1
3 542200 211 CABLE , HC Harness Connector Plate Assembly P3 P30,P31, P32 1
4 542200 210 CABLE, Wire Harness, Valve Body, Left Side P21 Valve Body, Left - Y11,
Y21, Y31, Y41, Y51, Y61
1
5 542200 209 CABLE, Wire Harness, Valve Body, Right Side P22 Valve Body, Right - Y12,
Y22, Y32, Y42, Y52, Y62
1
6 542200 212 CABLE, Wire Harness, Translation P4 P40 1
7 P 150832 340 CABLE, Wire Harness, Floor Lock P1 Floor Lock Manifold 1
8 P 129359 521 + CONNECTOR (Pump 2–Pin) TB3 Pump 1
9 413724 403 OVERRIDE HAND CONTROL
ASSEMBLY
P50 P5 1
10 542200 216 CABLE, Tilt With Sensor Assembly P71 Tilt Sensor 1
11 542200 238 CABLE, Trendelenburg Sensor P72 Trend Sensor 1
12 542200 025 CABLE, Leg Sensor Assembly P73 Leg Sensor 1
13 542200 090 CABLE, Sensor/Back Section Assembly P74 Back Sensor 1
14 542200 194 CABLE, Height Sensor (With Wire) P75 Height Sensor 1
15 542200 196 CABLE, Slide Sensor (With Wire) P76 Slide Sensor 1
16 542200 220 CABLE, Kidney Bridge Switch Assembly P77 Kidney Lock Switch 1
17 542200 221 CABLE, Leg Section Limit Switch Assembly P78 Leg Switch 1
18 542200 208 CABLE, Wire Harness, Charger TB4 P6 1
19 P 150832 490 CABLE ASSEMBLY, Fuse/Battery/Charger TB2 F1/Batteries 1
20 P 764333 102 • HOLDER, Fuse TB2 F1/Batteries 1
21 542200 207 CABLE, Translation Sensor TB6 Power Slide Board 1
22 689400 009 CABLE, Main Power Cord
Power Supply/
Battery Charger
AC Power 1
23 691300 001 * FERRITE, 6-7.5 Cable
Power Supply/
Battery Charger
1
24 688100 015 † VOLTAGE SUPPRESSOR
Sliding Motor
Assembly
1
25 P 150832 448 FOOT CONTROL, 4085 Table (Not Shown) P30 1
* Item #23 is not included with Item #19.
†
Item #24 is not included with sliding motor assembly.
+
Item #8 is not included in Pump 342211-555.
