USB on-the-go full-speed (OTG_FS) RM0090

1282/1731 DocID018909 Rev 11

OTG_FS Host periodic transmit FIFO size register (OTG_FS_HPTXFSIZ)

Address offset: 0x100

Reset value: 0x0200 0600

OTG_FS device IN endpoint transmit FIFO size register (OTG_FS_DIEPTXFx)

(x = 1..3, where x is the FIFO_number)

Address offset: 0x104 + (FIFO_number – 1) × 0x04

Reset value: 0x02000400

313029282726252423222120191817161514131211109876543210

PTXFSIZ PTXSA

r/r

Bits 31:16 PTXFD: Host periodic TxFIFO depth

This value is in terms of 32-bit words.

Minimum value is 16

Bits 15:0 PTXSA: Host periodic TxFIFO start address

The power-on reset value of this register is the sum of the largest Rx data FIFO depth and

largest non-periodic Tx data FIFO depth.

313029282726252423222120191817161514131211109876543210

INEPTXFD INEPTXSA

r/r

Bits 31:16 INEPTXFD: IN endpoint TxFIFO depth

This value is in terms of 32-bit words.

Minimum value is 16

The power-on reset value of this register is specified as the largest IN endpoint FIFO

number depth.

Bits 15:0 INEPTXSA: IN endpoint FIFOx transmit RAM start address

This field contains the memory start address for IN endpoint transmit FIFOx. The address

must be aligned with a 32-bit memory location.
