Flexible memory controller (FMC) RM0090
1594/1731 DocID018909 Rev 11
Figure 455. FMC memory banks
37.4.1 NOR/PSRAM address mapping
HADDR[27:26] bits are used to select one of the four memory banks as shown in Table 249.
"ANK
X-"
./2032!-32!-
3UPPORTEDMEMORYTYPE"ANK
X
!DDRESS
0##ARD
-36
3$2!-
X&&&&&&&
X
X&&&&&&&
X
X&&&&&&&
X
X&&&&&&&
X#
X#&&&&&&&
X$
X$&&&&&&&
"ANK
X-"
"ANK
X-"
"ANK
X-"
3$2!-"ANK
X-"
3$2!-"ANK
X-"
.!.$&LASHMEMORY
Table 249. NOR/PSRAM bank selection
HADDR[27:26]
(1)
1. HADDR are internal AHB address lines that are translated to external memory.
Selected bank
00 Bank 1 - NOR/PSRAM 1
01 Bank 1 - NOR/PSRAM 2
10 Bank 1 - NOR/PSRAM 3
11 Bank 1 - NOR/PSRAM 4
