DocID018909 Rev 11 79/1731

RM0090 Embedded Flash memory interface

112

System memory 0x1FFF 0000 - 0x1FFFF 77FF 30 Kbytes

OTP 0x1FFF 7800 - 0x1FFF 7A0F 528 bytes

Option bytes

0x1FFF C000 - 0x1FFF C00F 16 bytes

0x1FFE C000 - 0x1FFE C00F 16 bytes

Table 8. 1 Mbyte single bank Flash memory organization

(STM32F42xxx and STM32F43xxx) (continued)

Block Bank Name Block base addresses Size

Table 9. 1 Mbyte dual bank Flash memory organization (STM32F42xxx and STM32F43xxx)

Block Name Block base addresses Size

Main memory

Bank 1

Sector 0 0x0800 0000 - 0x0800 3FFF 16 Kbytes

Sector 1 0x0800 4000 - 0x0800 7FFF 16 Kbytes

Sector 2 0x0800 8000 - 0x0800 BFFF 16 Kbytes

Sector 3 0x0800 C000 - 0x0800 FFFF 16 Kbyte

Sector 4 0x0801 0000 - 0x0801 FFFF 64 Kbytes

Sector 5 0x0802 0000 - 0x0803 FFFF 128 Kbytes

Sector 6 0x0804 0000 - 0x0805 FFFF 128 Kbytes

Sector 7 0x0806 0000 - 0x0807 FFFF 128 Kbytes

Bank 2

Sector 12 0x0808 0000 - 0x0808 3FFF 16 Kbytes

Sector 13 0x0808 4000 - 0x0808 7FFF 16 Kbytes

Sector 14 0x0808 0000 - 0x0808 BFFF 16 Kbytes

Sector 15 0x0808 C000 - 0x0808 FFFF 16 Kbytes

Sector 16 0x0809 0000 - 0x0809 FFFF 64 Kbytes

Sector 17 0x080A 0000 - 0x080B FFFF 128 Kbytes

Sector 18 0x080C 0000 - 0x080D FFFF 128 Kbytes

Sector 19 0x080E 0000 - 0x080F FFFF 16 Kbytes

System memory 0x1FFF 0000 - 0x1FFF 77FF 30 Kbytes

OTP 0x1FFF 7800 - 0x1FFF 7A0F 528 bytes

Option bytes

Bank 1 0x1FFF C000 - 0x1FFF C00F 16 bytes

Bank 2 0x1FFE C000 - 0x1FFE C007 16 bytes
