Flexible memory controller (FMC) RM0090

1626/1731 DocID018909 Rev 11

11 WAITCFG 0x0

10 WRAPMOD 0x0

9 WAITPOL to be set according to memory

8 BURSTEN no effect on synchronous write

7 Reserved 0x1

6 FACCEN Set according to memory support

5-4 MWID As needed

3-2 MTYP[1:0] 0x1

1 MUXEN As needed

0 MBKEN 0x1

Table 283. FMC_BTRx bit fields

Bit No. Bit name Value to set

31-30 Reserved 0x0

29:28 ACCMOD 0x0

27-24 DATLAT Data latency

23-20 CLKDIV

0x0 to get CLK = HCLK (not supported)

0x1 to get CLK = 2 × HCLK

19-16 BUSTURN Time between NEx high to NEx low (BUSTURN HCLK)

15-8 DATAST Don’t care

7-4 ADDHLD Don’t care

3-0 ADDSET[3:0] Don’t care

Table 282. FMC_BCRx bit fields (continued)

Bit No. Bit name Value to set
