STMicroelectronics STM32F429 Reference Manual

Cryptographic processor (CRYP) RM0090
754/1731 DocID018909 Rev 11
23.6.13 CRYP register map
Table 113. CRYP register map and reset values for STM32F415/417xx
Offset
Register
name and
reset value
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12
11
10
9 8 7 6 5 4 3 2 1 0
0x00
0x00
CRYP_CR
Reserved
CRYPEN
FFLUSH
Reserved
KEYSIZE
DATATYPE
ALOMODE[2:0]
ALGODIR
Res.
Reset value 00 00000000
0x04
CRYP_SR
Reserved
BUSY OFFU
OFNE
IFNF
IFEM
Reset value 00011
0x08
CRYP_DIN DATAIN
Reset value 0000000000000
0x0C
CRYP_DOUT DATAOUT
Reset value 0000000000000
0x10
CRYP_DMAC
R
Reserved
DOEN
DIEN
Reset value 00
0x14
CRYP_IMSC
R
Reserved
OUTIM
INIM
Reset value 00
0x18
CRYP_RISR
Reserved
OUTRIS
INRIS
Reset value 01
0x1C
CRYP_MISR
Reserved
OUTMIS
IN%IS
Reset value 00
0x20
CRYP_K0LR CRYP_K0LR
Reset value 00000000000000000000000000000000
0x24
CRYP_K0RR CRYP_K0RR
Reset value 00000000000000000000000000000000
...
0x38
CRYP_K3LR CRYP_K3LR
Reset value 00000000000000000000000000000000
0x3C
CRYP_K3RR CRYP_K3RR
Reset value 00000000000000000000000000000000
0x40
CRYP_IV0LR CRYP_IV0LR
Reset value 00000000000000000000000000000000
