DocID018909 Rev 11 663/1731

RM0090 General-purpose timers (TIM9 to TIM14)

687

19.4.2 TIM9/12 slave mode control register (TIMx_SMCR)

Address offset: 0x08

Reset value: 0x0000

1514131211109876543210

Reserved

MSM TS[2:0]

Res.

SMS[2:0]

rw rw rw rw rw rw rw

Bits 15:8 Reserved, must be kept at reset value.

Bit 7 MSM: Master/Slave mode

0: No action

1: The effect of an event on the trigger input (TRGI) is delayed to allow a perfect

synchronization between the current timer and its slaves (through TRGO). It is useful in

order to synchronize several timers on a single external event.
