STMicroelectronics STM32F429 Reference Manual

DocID018909 Rev 11 787/1731
RM0090 Hash processor (HASH)
788
0x314
HASH_HR1 H1
Reset value 00000000000000000000000000000000
0x318
HASH_HR2 H2
Reset value 00000000000000000000000000000000
0x31C
HASH_HR3 H3
Reset value 00000000000000000000000000000000
0x320
HASH_HR4 H4
Reset value 00000000000000000000000000000000
Table 117. HASH register map and reset values on STM32F43xxx
Offse
t
Register
name
reset value
Register size
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12
11
10
9 8 7 6 5 4 3 2 1 0
0x00
HASH_CR
Reserved
ALGO[1]
Reserved
LKEY
Reserved
MDMAT
DINNE
NBW
ALGO[0]
MODE
DATATYPE
DMAE
INIT
Reserved
Reset value 0 0 000000000000
0x04
HASH_DIN DATAIN
Reset value 00000000000000000000000000000000
0x08
HASH_STR
Reserved
DCAL
Reserved
NBLW
Reset value 0 00000
0x0C
HASH_HR0 H0
Reset value 00000000000000000000000000000000
0x10
HASH_HR1 H1
Reset value 00000000000000000000000000000000
0x14
HASH_HR2 H2
Reset value 00000000000000000000000000000000
0x18
HASH_HR3 H3
Reset value 00000000000000000000000000000000
0x1C
HASH_HR4 H4
Reset value 00000000000000000000000000000000
Table 116. HASH register map and reset values on STM32F415/417xx (continued)
Offset
Register
name
reset value
Register size
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12
11
10
9 8 7 6 5 4 3 2 1 0
