DocID018909 Rev 11 1703/1731

RM0090 Device electronic signature

1703

Address offset: 0x08

Read only = 0xXXXX XXXX where X is factory-programmed

39.2 Flash size

Base address: 0x1FFF 7A22

Address offset: 0x00

Read only = 0xXXXX where X is factory-programmed

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

U_ID(95:80)

rrrrrrrrrrrrrrrr

1514131211109876543210

U_ID(79:64)

rrrrrrrrrrrrrrrr

Bits 31:0 U_ID(95:64): 95:64 Unique ID bits.

1514131211109876543210

F_SIZE

rrrrrrrrrrrrrrrr

Bits 15:0 F_ID(15:0): Flash memory size

This bitfield indicates the size of the device Flash memory expressed in Kbytes.

As an example, 0x0400 corresponds to 1024 Kbytes.
