RM0090 General-purpose timers (TIM9 to TIM14)
687
19.4.13 TIM9/12 register map
TIM9/12 registers are mapped as 16-bit addressable registers as described below:
Table 102. TIM9/12 register map and reset values
Offset Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12
11
10
9 8 7 6 5 4 3 2 1 0
0x00
TIMx_CR1
Reserved
CKD
[1:0]
ARPE
Reserved
OPM
URS
UDIS
CEN
Reset value 000 0000
0x08
TIMx_SMCR
Reserved
MSM
TS[2:0]
Reserved
SMS[2:0]
Reset value 000 0 000
0x0C
TIMx_DIER
Reserved
TIE
Reserved
CC2IE CC1IE
UIE
Reset value 0000
0x10
TIMx_SR
Reserved
CC2OF CC1OF
Reserved
TIF
Reserved
CC2IF CC1IF
UIF
Reset value 00 0 000
0x14
TIMx_EGR
Reserved
TG
Reserved
CC2G CC1G
UG
Reset value 0000
0x18
TIMx_CCMR1
Output Compare
mode
Reserved
OC2M
[2:0]
OC2PE
OC2FE
CC2S
[1:0]
Reserved
OC1M
[2:0]
OC1PE
OC1FE
CC1
S
[1:0]
Reset value 0 0 0 0 0 0 0 0 0 0 0 0 0 0
TIMx_CCMR1
Input Capture
mode
Reserved
IC2F[3:0]
IC2
PSC
[1:0]
CC2S
[1:0]
IC1F[3:0]
IC1
PSC
[1:0]
CC1
S
[1:0]
Reset value 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0x1C
Reserved
0x20
TIMx_CCER
Reserved
CC2NP
Reserved
CC2P CC2E
CC1NP
Reserved
CC1P CC1E
Reset value 000000
0x24
TIMx_CNT
Reserved
CNT[15:0]
Reset value 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0x28
TIMx_PSC
Reserved
PSC[15:0]
Reset value 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0x2C
TIMx_ARR
Reserved
ARR[15:0]
Reset value 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0x30
Reserved
0x34
TIMx_CCR1
Reserved
CCR1[15:0]
Reset value 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
