System configuration controller (SYSCFG) RM0090

302/1731 DocID018909 Rev 11

9.3.7 Compensation cell control register (SYSCFG_CMPCR)

Address offset: 0x20

Reset value: 0x0000 0000

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

Reserved

1514131211109 8 7 654321 0

Reserved

READY

Reserved

CMP_PD

r rw

Bits 31:9 Reserved, must be kept at reset value.

Bit 8 READY: Compensation cell ready flag

0: I/O compensation cell not ready

1: O compensation cell ready

Bits 7:2 Reserved, must be kept at reset value.

Bit 0 CMP_PD: Compensation cell power-down

0: I/O compensation cell power-down mode

1: I/O compensation cell enabled
