DocID018909 Rev 11 783/1731

RM0090 Hash processor (HASH)

788

Note: When starting a digest computation for a new bit stream (by writing the INIT bit to 1), these

registers assume their reset values.

25.4.6 HASH interrupt enable register (HASH_IMR)

Address offset: 0x20

Reset value: 0x0000 0000

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

rrrrrrrrrrrrrrrr

1514131211109876543210

rrrrrrrrrrrrrrrr

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

Reserved

1514131211109876543210

Reserved

DCIE DINIE

rw rw

Bits 31:2 Reserved, forced by hardware to 0.

Bit 1 DCIE: Digest calculation completion interrupt enable

0: Digest calculation completion interrupt disabled

1: Digest calculation completion interrupt enabled.

Bit 0 DINIE: Data input interrupt enable

0: Data input interrupt disabled

1: Data input interrupt enabled
