8.3.15 Selection of RTC_AF1 and RTC_AF2 alternate functions
The STM32F4xx feature two GPIO pins RTC_AF1 and RTC_AF2 that can be used for the
detection of a tamper or time stamp event, or RTC_ALARM, or RTC_CALIB RTC outputs.
• The RTC_AF1 (PC13) can be used for the following purposes:
RTC_ALARM output: this output can be RTC Alarm A, RTC Alarm B or RTC Wakeup
depending on the OSEL[1:0] bits in the RTC_CR register
• RTC_CALIB output: this feature is enabled by setting the COE[23] in the RTC_CR
register
• RTC_TAMP1: tamper event detection
• RTC_TS: time stamp event detection
The RTC_AF2 (PI8) can be used for the following purposes:
• RTC_TAMP1: tamper event detection
• RTC_TAMP2: tamper event detection
• RTC_TS: time stamp event detection
The selection of the corresponding pin is performed through the RTC_TAFCR register as
follows:
• TAMP1INSEL is used to select which pin is used as the RTC_TAMP1 tamper input
• TSINSEL is used to select which pin is used as the RTC_TS time stamp input
• ALARMOUTTYPE is used to select whether the RTC_ALARM is output in push-pull or
open-drain mode
The output mechanism follows the priority order listed in Table 37 and Table 38.
Table 37. RTC_AF1 pin
(1)
Pin
configuration
and function
RTC_ALARM
enabled
RTC_CALIB
enabled
Tamper
enabled
Time
stamp
enabled
TAMP1INSEL
TAMPER1
pin selection
TSINSEL
TIMESTAMP
pin
selection
ALARMOUTTYPE
RTC_ALARM
configuration
Alarm out
output OD
1Don’t care
Don’t
care
Don’t
care
Don’t care Don’t care 0
Alarm out
output PP
1Don’t care
Don’t
care
Don’t
care
Don’t care Don’t care 1
Calibration
out output PP
01
Don’t
care
Don’t
care
Don’t care Don’t care Don’t care
TAMPER1
input floating
0 0 1 0 0 Don’t care Don’t care
TIMESTAMP
and
TAMPER1
input floating
0 0 1 1 0 0 Don’t care
TIMESTAMP
input floating
0 0 0 1 Don’t care 0 Don’t care
Standard
GPIO
0 0 0 0 Don’t care Don’t care Don’t care
1. OD: open drain; PP: push-pull.
