7.2 Communication with SDS 5000
By setting up an Integrated Bus (IGB), you have different possibilities for
communication with one or more SDS 5000 units:
• a direct connection between the inverter and PC
• a remote maintenance connection via a local network (LAN)
• a remote maintenance connection via the internet
The connection via a local network or the internet is described in the SDS 5000
operating manual, see section 1.2 Other manuals. A direct connection is only
described in this section.
A direct connection is the direct connection of a PC with POSITool to a SDS 5000
or an IGB network via a cable without other network components for the purpose
of commissioning, diagnostics or maintenance. You can establish a direct
connection with a SDS 5000 or an IGB network.
7.2.1 Basics of IGB communication
Communication uses the following interfaces:
• Direct connection: TCP/IP protocol on port 37915 and UDP/IP protocol on
port 37915
• Remote maintenance without proxy server: HTTP protocol on port 80
• Remote maintenance with proxy server: HTTP protocol on port of the proxy
server
You may be asked to share this port by the personal firewall. Share these port for
your firewall. To do this, contact your network administrator.
The IGB network must meet the following conditions:
• A maximum of 32 SDS 5000s may be connected in one network.
• All inverters involved in the IGB network must be directly connected with each
other. No other components such as hubs and switches are permitted
between them in the circuit.
• The overall resulting layout must be a line topology.
• The X3 A interfaces may only be connected with X3 B interfaces of other
inverters and vice versa.
• Suitable cables must be used. STÖBER ANTRIEBSTECHNIK provides
ready-made cables for the layout of the Integrated Bus. These cables must
be used to ensure proper functionality. Note also the SDS 5000 projecting
manual.
It is also possible to use cables with the following specification:
Information
Remember that an IGB network can never be accessed by remote
maintenance and direct connection (PC) at the same time.
