STRIDE SE-SW5U - Alarm Configuration; Mirror Configuration; VLAN Configuration; Port Configuration

Stride Industrial Ethernet Switches User Manual 2nd Ed. Rev. B
Appendix C - Switch Settings
Alarm Configuration
Mirror Configuration
VLAN Configuration
Port Configuration
Name
Port 2 Port 3 Port 4 Port 5 Port 6 Port 7 Port 8
Admin
Enabled Enabled Enabled Enabled Enabled Enabled Enabled Enabled
Negotiation
Enabled Enabled Enabled Enabled Enabled Enabled Enabled Enabled
Speed / Duplex
00080f 00080f 00080f 00080f 00080f 00080f 00080f 00080f
Flow Control
Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled
Exclude
Included Included Included Included Included Included Included Included
Priority
128 128 128 128 128 128 128 128
Path Cost
200000 200000 200000 200000 200000 200000 200000 200000
Type
Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled
Point-to-Point
Auto Auto Auto Auto Auto Auto Auto Auto
Path Cost Auto
Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled
VLAN Mode
Disabled
Number of VLAN’s
0
Port 1 Port 2 Port 3 Port 4 Port 5 Port 6 Port 7 Port 8
PVID
1 1 1 1 1 1 1 1
Force
Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled
Monitor Port
1
Port 1 Port 2 Port 3 Port 4 Port 5 Port 6 Port 7 Port 8
Direction
none none none none none none none none
Ports to Monitor
A power input lost
Enabled
Port 1 Port 2 Port 3 Port 4 Port 5 Port 6 Port 7 Port 8
link down
Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled
