STRIDE SE-SW5U - QOS Configuration

Stride Industrial Ethernet Switches User Manual 2nd Ed. Rev. B
Appendix C - Switch Settings
QOS Configuration
Schedule
strict
Tag 0 Priority
1
Tag 1 Priority
0
Tag 2 Priority
0
Tag 3 Priority
1
Tag 4 Priority
2
Tag 5 Priority
2
Tag 6 Priority
3
Tag 7 Priority
3
Port 1 Port 2 Port 3 Port 4 Port 5 Port 6 Port 7 Port 8
Use 802.1p Tag
Priority
Enabled Enabled Enabled Enabled Enabled Enabled Enabled Enabled
Use IP ToS/DiffServ
Enabled Enabled Enabled Enabled Enabled Enabled Enabled Enabled
Priority Precedence
tag tag tag tag tag tag tag tag
Default Out Q
1 1 1 1 1 1 1 1
Path Cost Auto
normal normal normal normal normal normal normal normal
C-4
