Stride Industrial Ethernet Switches User Manual 2nd Ed. Rev. B
Appendix D - CLI Commands
Alarm Configuration:
Alarm Configuration
Parameter Default Allowable Values / Description
list
n/a No value, view all current alarm settings
powerloss
enabled ‘enabled’, ‘disabled’ / alarm output will be low if a power input is lost
ringfailure
disabled ‘enabled’, ‘disabled’ / alarm output will be low if a power input is lost
These settings require a port number, usage:
alarm <parameter> <port #> [<new value>]
linkloss
disabled
0 - ‘enabled’, ‘disabled’ / alarm output is triggered when link is down on the
specified port
Modbus Configuration:
Modbus Configuration
Parameter Default Allowable Values / Description
enabled
0 0 or 1, 1 meaning enabled
stanum
1 1 to 247, used to get or set modbus station number
transport
tcp+udp tcp / udp / tcp+udp, used to specify allowed transport layer for modbus
timeout
0 0 to 3600 or none, time is in seconds
maxcon
4 1 to 20, sets maximum number of concurrent connections
port
502 1 to 65535, set port number to listen for Modbus polling requests
Info Configuration:
Info Configuration
Parameter Default Allowable Values / Description
fwversion
n/a View the current firmware version
cfgversion
n/a View the configuration version number
macaddr
n/a View the MAC address of the Switch
link
n/a ‘all’, port# / show specified port (s) link status
support
n/a displays useful support information (IP, etc.)
These settings require a filter to be specified:
info <parameter> <filter> [<value>]
For the info mactable command, the filter parameters are:
id = {*|#} Show all/one specific filtering database by ID
port = {*|#[,#[,…]]} Show all/one/multiple specific port(s)
NOTE: port 33 is the switch CPU.
mac = {*|xx}:{*|xx}:{*|xx}:{*|xx}:{*|xx}:{*|xx} Show only MAC addresses matching the given
pattern
D-4
