Technical Specifications
Technical Specs
Here are the hardware technical specifications for the industrial Ethernet switches and media
converters covered by this manual.
Technical Specifications continued on the next page.
General Specifications
Ethernet switch type
Unmanaged or Managed
Operating mode
Store & forward, wire speed switching, non-blocking
Devices supported
All IEEE 802.3 compliant devices are supported
Protocols
(managed models only)
SNMPv1/v2/v3, RMON, DHCP, SNTP, TFTP, STP, RSTP, QoS/CoS/ToS/DS, IGMPv1/v2,
VLAN (tag and port based), HTTP, HTTPS (SSL & TSL), Telnet, SSH and more
Industrial Protocols supported
Modbus/TCP, EtherNet/IP, PROFInet, Foundation Fieldbus HSE and others
Standards
(depends on model)
IEEE 802.3, 802.3u, 802.3ab/z, 802.3x, 802.1D/w, 802.1p, 802.1Q and others
Management Interfaces
(managed models only)
Web, text (Telnet & SSH), CLI (command line
interface) and SNMP (see Chapter 2 - Managed Switch Software for supported MIBs)
MAC addresses
1024 on unmanaged models;
2048 on managed models with 5, 8 or 9 ports
8192 on Gigabit models with more than 9 ports
Memory bandwidth
3.2 Gbps on models with 9 or fewer ports
3.2 Gbps on models with more than 9 ports
Latency for 10 Mbps ports*
16 us + frame time (typical)
Latency for 100 Mbps ports*
< 5 us + frame time (typical)
Ethernet isolation
1500 VRMS 1 minute
Management Serial Port
(managed models only)
RS232 (TXD, RXD and GND), 9600, 8, N, 1 fixed and/or mini-USB
* Varies on load and settings
1-31
Chapter 1 - Hardware
Stride Industrial Ethernet Switches User Manual 2nd Ed. Rev. B
