Appendix D - CLI Commands
RSTP Configuration:
RSTP Configuration
Parameter Default Allowable Values / Description
protocol
none none, stp, rstp or mstp / View or change the spanning tree protocol
priority
0 A multiple of 4096 in the range of 0 - 61440 / View or change the priority
mma
6
An integer in the range 6 - 40 / View or change the maximum message
age
hellowtime
1 An integer in the range 1 - 10 / View or change the hello time
fwddelay
4 An integer in the range 4 - 30 / View or change the forwarding delay
Txlimit
1 An integer in the range 1 - 10 / View or change the transmission limit
region
n/a any valid region name
cfgrevision
n/a any valid revision number
maxhops
20 any number from 6 - 40
The settings below require a port number, usage:
rstp <parameter> <port #> [<new value>]
exclude
0 ‘2’, ‘1’, ‘0’ / View or change whether this port is excluded from STP
pprio
0 An integer in the range of 0 - 240 / View or change this port’s priority
pcost
none
‘auto’ or integer in the range of 0 - 200,000,000 / View or change this port’s
cost
type
1 ‘1’, ‘0’ / View or change this port’s edge type
ptp
Auto
‘ForceTrue’, ‘ForceFalse’, ‘Auto’ / View or change this port’s point-to-point
setting
QoS Configuration:
QoS Configuration
Parameter Default Allowable Values / Description
schedule
strict ‘strict’, ‘fair’ / View or change the fairness rule
The settings below require a port number, usage:
qos <parameter> <port #> [<new value>]
usetag
0 ‘0’, ‘1’ / View or change whether tag priorities are used
useip
n/a ‘0’, ‘1’ / View or change whether IP priorities are used
pref
tag ‘tag’, ‘ip’ / View or change which to use if both tags and IP are enabled
priority
1 0 - 3 / Defaul priority to give to packets received on this port
type
normal ‘normal’, ‘add’, ‘remove’, ‘double’ / The type of connection to this port
The setting below requires a tag number, usage:
qos tag <tag #> [<new value>]
tag
(depends
on the tag)
0 - 3 / View or change the priority of the specified tag
If <new value> is not present, the current setting will be displayed.
