Stride Managed Switch Default Settings (cont’d)
Configuration Parameter Default Setting
Redundancy Settings
Spanning Tree Settings
Redundancy Protocol
Rapid Spanning Tree Protocol
Bridge Priority
32768
Maximum Age
20
Hello Time
2
Forward Delay
15
Transmission Limit
6
Region Name
Configiguration Revision
0 (grayed out)
Max Hops
20 (grayed out)
MST Instance
None by default
Spanning Tree Port
Settings
Exclude
Off for all ports
Priority
128 for all ports
Path Cost
20000 for all 10 / 100 / 1000 Ports,
200,000 for all 10 / 100 ports
Type
Auto for all ports
Point-to-Point
Auto for all ports
Real-time Ring Settings
Enable
Off for all ports
Ring Name
Ring x (x being port number) Grayed out by default
Primary Port
none
Backup Port
none
Ring Master
Automatic Master
Settings
QoS/CoS Settings
Priority Frame Setting
Send all high priority fames before any others
Use 802.1p Tag Priority
On for all ports
Use IP ToS/DiffServ
On for all ports
Priority Precedence
Tag for all ports
Default Out Q
Normal for all ports
Type
Transparent for all ports
802.1p Tag Settings
Priority 0 (Best Effort)
Normal
Background
Priority 2 (Spare)
Background
Priority 3 (Excellent Effort)
Normal
Priority 4 (Controlled Load)
Expedited
Priority 5 (Video)
Expedited
Priority 6 (Voice)
Urgent
Priority 7 (Network Control)
Urgent
Message Rate Limiting
Limit Broadcast and
Multicast
Disabled for all ports
Forward Unknown
Enabled for all ports
