www.stryker.com 2030-809-002 REV D 127
EPIC, EPIC PLUS, Litter Assembly, iBed Awareness Option, Standard Components - 2032-331-010
Item Part No Part Name Qty.
E 0003-224-000 Hex Washer Head Screw 16
L 0004-443-000 Button Head Cap Screw 4
U 0007-058-000 Truss Head Torx Screw 25
AF 0013-018-000 External Tooth Lock Washer 16
AT 0025-050-000 Dome Head Rivet 24
BF 0030-045-000 Strain Relief 3
BG 0030-047-000 Right Angle Strain Relief 3
BH 0030-052-000 Snap Bushing 4
BV 0059-106-000 Strain Relief 1
CA 0059-157-000 Power Supply 1
CE 0059-751-000 Universal Board Mount 6
CG 0059-773-000 Push Spacer 3
CH 0059-774-000 Locking Circuit Board Support 1
EB 2035-031-100 Wire Channel Cover 2
FE 2040-031-056 Foley Holder 6
FJ 3000-300-115 Standoff 4
GH 3003-300-216 LBS Bracket Mount. Plate 1
GJ 3003-407-900 LBS CPU Assembly 1
GK 3004-300-225 LBS Indicator Ass’y, Right 1
GL 3004-300-230 LBS Indicator Ass’y, Left 1
GR 0038-111-000 Cable Tie 2
GU 3002-300-870 Ground Strap 8
GV 2035-031-801 Inlet/Fuse Cable 1
GW 2032-300-802 Footboard/CPU Cable 1
GY 2035-031-048 CPR Cable Assembly, Short 1
HA 2035-031-049 CPR Cable Assembly, Long 1
HB 2035-032-801 Gatch Limit Switch Cable 1
HC 2035-032-802 Fowler/CPU Jumper Cable 1
HD 2035-032-803 Fowler Pot Cable 1
HE 2035-032-804 Fuse/PCB Cable 1
HF 3001-300-877 Siderail Extension Cable 1
HG 5010-080-007 Cable Power Supply Ground 1
HH 2030-031-801 Foot Pot Extension Cable 1
HJ 2030-031-802 Head Pot Extension Cable 1
HK 2030-031-803 Head Lift Motor Extension 1
HN 2035-032-805 Cable CPU/Power Supply 1
HP 2035-020-805 Siderail Limit Switch bypass Cable 2
HR 2032-300-801 Footboard to CPU Cable, Epic 1
HT 2032-400-804 CPU to Siderail Cable 1
Litter Assembly, iBed Awareness Option, Std. Components
