OPTIONAL SMART TV INTERFACE “BURN-IN” PROCEDURE
This procedure is used for selecting the style of TV interface needed for your bed. If traditional TV is desired, no
calibration is required. If optional Smart TV is available on the bed, select one of the TV manufacturers listed in the
table below.
Setup
• Ensure the communication cable is connected between the bed and the Db37 wall port or the pillow speaker port
of the nurse call system. If available, a bed communication tester can be used instead of the hospital wiring.
Procedure
1. Place the bed in the lift potentiometer burn-in mode.
2. Notice the Nurse Call LED (yellow) is flashing. Notice the Nurse Answer LED (green) is flashing on/off slowly.
3. Press and release the TV ON/OFF switch on the bed’s siderail once. Notice the Nurse Call LED flashes once. This
is the first selection of TV manufacturers for the Smart TV mode. Notice the Nurse Answer LED (green) is flashing
on/off slowly. The Nurse Answer LED will only light when the Nurse Call LED (yellow) is flashing.
4. Press and release the TV ON/OFF switch on the bed’s siderail to scroll to other TV manufacturers. Notice the
number of times the Nurse Call LED flashes matches the number listed in the table below and represents the
TV manufacturer selected.
5. When the desired TV manufacturer has been selected, unplug the bed power cord from the wall socket and plug
it back in to complete the Smart TV burn-in procedure.
Note
If the bed is connected to a television during the burn-in procedure, the television will turn on when the correct setting
is selected.
TV MANUFACTURER SELECTION FOR SMART TV BURN-IN PROCEDURE
Press and release TV ON/OFF switch: Nurse Call LED (Yellow) TV Manufacturer
One time One flash RCA 1
Two time Two flash RCA 2
Three time Three flash Zenith 1
Four time Four flash Zenith 2
Five time Five flash Philips/Magnavox
Six time Six flash Magnavox (models 9120, 9220, 9320)
Seven time Seven flash Traditional Plus
Eight time Eight flash Traditional TV
Nine time Nine flash Auto Detect: Smart TV
Ten time Ten flash Auto Detect W/Digital Volume Smart TV
