Stryker EPIC II Service Manual

Return To Table of Contents
24 2030-809-002 REV D www.stryker.com
iBED Awareness System Error Codes
Error
Code
Name Description Type Affected Systems
300 Not Used Side Rails
301 HLSRSwitch Head Left Side Rail Switch General. Logged iBED Awareness
302 HRSRSwitch Head Right Side Rail Switch General. Logged iBED Awareness
303 FLSRSwitch Foot Left Side Rail Swtich General. Logged iBED Awareness
304 FRSRSwtich Foot Right Side Rail Switch General. Logged iBED Awareness
400 Not Used Memory System
401 EEPROM EEPROM Memory Corruption
Any detected non recoverable memory failure
will produce an error and localize the error to
a section of memory.
Logged
500 Not Used Motion System
ERROR MESSAGES
Error
Code
Name Description Type Affected Systems
800 Not Used Non-Logged Errors
801 NurseCallBattery When the nurse call battery falls below the 5v
threshold a message will appear in the lower
status window “N/C Battery Low”.
Non-Logged N/A
802 LiftCalibration When the lift calibration has not been
completed then when in normal mode the
message “Lift Calib. Err” will be displayed in
the lower status screen window.
Non-Logged N/A
803 FowlerCalibration When the fowler calibration has not been
completed then when in normal mode the
message “Fowler Calib. Err” will be displayed
in the lower status screen window.
Non-Logged N/A
804 ScaleCalibration Scale Calibration error occurs when the
product in a normal operation mode and the
scale system is present on the product but
the scale system has not been calibrated. The
message “Scale Calib. Err” will be displayed
in the lower status screen window.
Non-Logged N/A
LOGGED ERRORS (CONTINUED)
