www.stryker.com 2030-809-002 REV D 23
iBED Awareness System Error Codes
ERROR HANDLING
• The error handling system provides a mechanism for capturing errors known to the product and providing feedback
to the operator through logged errors or message errors.
• All Logged errors generate a generic blinking error message which will be displayed on the status screen in the
lower area: “Error XXX Call Service”, where XXX is the error code.
• Errors will only be logged if the error log does not already contain the error.
• In the event multiple errors are displayed on the status screen, the error code is used to identify the priority. The
lowest code has the highest priority.
• All logged errors and message errors are persistent until the power is cycled, or the condition is fixed.
• The details for each logged error and error message are detailed in the table below.
LOGGED ERRORS
Error
Code
Name Description Type Affected Systems
100 Not Used Highest Priority Errors
102 StuckSafetyRelay This error is checked while the product is
“On”. If the safety relay signal is “On” and
there is no button press on the product then
set this error after 1 minute.” Note: This should
not be checked when in Auto-Cycle Mode.
Logged Motion
103 InputTimer If any footboard motion or side rail/pendant
input is sensed to be “On” continuously for a
total of 5 minutes then provide an exception
message. Note: This should not be checked
when in Auto-Cycle Mode.
Logged Motion
200 Not Used Scale System
201 HL-Load Cell Patient Head Left Load Cell. Under/Over
range.
Logged Scale, Bed Exit,
iBED Awareness
202 HR-Load Cell Patient Head Right Load Cell. Under/Over
range.
Logged Scale, Bed Exit,
iBED Awareness
203 FL-Load Cell Patient Foot Left Load Cell. Under/Over
range.
Logged Scale, Bed Exit,
iBED Awareness
204 FR-Load Cell Patient Foot Right Load Cell. Under/Over
range.
Logged Scale, Bed Exit,
iBED Awareness
206 CS5533Fatal Non-Recoverable Communication Error.
CS5533 Fatal occurs when the CPU fails
to communicate to the External ADC for the
Load cells and cannot recover.
Logged Scale, Bed Exit,
iBED Awareness
207 ZeroFail Zero Fail error occurs when the system can-
not provide a stable zero value for three con-
secutive attempts at zeroing the product.
Logged Scale, Bed Exit,
iBED Awareness
