206 2030-809-002 REV D www.stryker.com
Item Part No. Part Name Qty.
A 0008-049-000 Socket Head Shoulder Bolt 2
B 0014-020-000 Thrust Washer 1
D 0016-028-000 Fiberlock Nut 2
E 0021-017-000 Set Screw 4
F 0037-214-000 Hole Plug 4
H 0038-133-000 Spring 1
J 0052-017-000 Spacer 2
K 1010-050-019 “Push/Pull” Label 1
L 1010-050-021 Long Strap 1
M 1010-050-050 Knob 1
N 1010-050-057 Max. Weight Label 4
P 1010-050-242 Lock Pin 1
R 2025-120-005 Equipment Label 1
S 2025-120-006 Specification Label 1
T 2025-120-018 Tray Assembly 1
W 2025-120-025 Pivot Weldment Frame 1
Optional Defibrillator Tray Assembly - 2025-120-010
