HEAD END MOTOR REMOVAL AND REPLACEMENT
Tools Required:
• T27 Torx
• 7/16” Socket Wrench
• Wire Cutters
Procedure:
1. Run the litter to the full up position and remove the mattress from the bed.
2. Fold the foot section back toward the head end of the bed. Electrically run the knee section to full up. If the knee
section will not move electrically, pull the foot section toward the head end of the bed while pulling the CPR release
handle (located at the head end of the bed). The knee section will raise.
3. Using a T27 Torx, remove the four screws holding the cover to the actuator box and remove the cover.
4. Remove the two CPR release cables from the CPR release bracket. Using a T27 Torx underneath the actuator box,
remove the two bolts holding the release bracket to the actuator box and remove the bracket from the actuator
box.
5. Disconnect all the electrical connections going to the head motor and move aside any wiring that could interfere
with the removal of the motor.
6. Using a 7/16” socket wrench underneath the actuator box, remove the four bolts holding the motor mounting
bracket to the actuator box. Lift up and out on the motor to remove it.
7. Remove the motor mounting bracket from the old motor and install it on the replacement motor.
8. Reverse steps 3 through 6 to install the replacement motor.
9. Verify the bed is working properly before returning it to service.
Service Information
