INTENDED USE
This manual is designed to assist you with the maintenance of Stryker Model 2030 Epic II
®
Critical Care Bed. Carefully
read this manual thoroughly before using the equipment or beginning maintenance on it. To ensure safe operation of
this equipment, it is recommended that methods and procedures be established for educating and training staff on the
safe operation of this bed.
Note
Epic II
®
PLUS and Epic II
®
+ are interchangeable terms within this manual.
Introduction
SPECIFICATIONS
Safe Working Load
Note: Safe Working Load indicates the sum of the
patient, mattress, and accessory weight.
500 lbs 227 kg
Bed Weight 594 lbs 269 kg
Scale System Capacity (optional equipment). Loads weighing up to 500 lbs 227 kg
Scale System Accuracy (optional equipment) ±1 pound of total patient weight at any bed
position
1
(patients weighing 100 pounds or less)
±1% of total patient weight at any bed position
1
(patients weighing greater than 100 pounds)
Overall Length/Width Length 91” 231 cm
Width 42.5” 108 cm
Minimum Bed Height 18” 46 cm
Maximum Bed Height (Standard)
Maximum Bed Height (Enhanced)
30” to 31”
32” to 33”
76.2 cm to 78.7 cm.
81.2 cm to 83.8 cm.
Fluoroscopy Access Epic II® 17” 43.1 cm
Epic II® PLUS 16” 41 cm
Knee Gatch Angle 0° to 30°
Back Angle 0° to 90°
Trendelenburg/Reverse Trendelenburg -12° to +12° ±2°
Electrical Requirements 120VAC, 60 Hz, 8.0 A
100VAC, 50/60 Hz, 9.0 A (Japan Option)
Battery Voltage (2) 12V, 31 Ah (Gel Cell Battery) Zoom® Option
(1) 9V (Alkaline Battery) Nurse Call Option
Noise Level > 65 dB
Outlet Option 120VAC, 5A, 60 Hz
1
If the bed is equipped with the enhanced height option, the scale accuracy is as described above for litter angles
from 0° to ±5° Trend.
MATTRESS SPECIFICATIONS
Thickness 6” 15.2 cm
Width >= 35” >= 88.9 cm
Length >= 84” >= 213.4
ILD 80 lbs 36.3 kg
The above stated mattress specifications assist in ensuring the product conforms to HBSW and IEC
specifications.
Stryker reserves the right to change specifications without notice.
Specifications listed are approximate and may vary slightly from unit to unit or by power supply fluctuations.
