OPTIONAL iBED AWARENESS MAINTENANCE MENU GUIDE
The Maintenance Menu contains all of the non-regularly accessible features of the product. This menu provides
an interface to the user and/or service personnel in order to provide the ability to control and access maintenance
features.
MAINTENANCE MENU ITEMS
The following are menu items listed in the maintenance menu screen:
1. Calib. Scale (Calibrate Scale)
2. TV Config. (TV Configuration)
3. Scale Info. (Scale Info/Stats)
4. Clear Statistics (Clear Scale Stats)
5. Error Log (View Error Log)
6. Clear Errors (Clear Error Log)
7. Scale Units (Lock Scale Units)
8. About (About Product)
9. Exit Menu (Exit Maintenance)
• Each of the menu items provide the operator with a different function.
• Using the up and down menu buttons you can scroll though the menu items.
• To select a menu item, scroll to the desired menu item using the Up and Down menu button. When the desired
feature is highlighted, press the Enter/Check button. Depending on the feature the display will move into the
sequence for the feature selected.
Load Cell Check
• This feature automatically checks all four load cells to make sure they are working properly.
• The purpose of this feature is to provide a self diagnostic of the load cells.
• When maintenance is entered a self-diagnostic feature should run and display results.
• While procedure is running the following message is displayed “Load Cell Check”.
• Any load cell errors will be displayed as a message “Load Cell Error” and then depending on the error an HL,
HR, FL or FR will be displayed below the message. (Refer to the Error Handling Section).
• If no errors are present then maintenance menu will be displayed and menu items 1-9 above may be
accessed.
Calibrate Scale
• This feature allows the operator to calibrate the scale system.
• This calibration is used to provide the system with a weight offset that occurs when the product is put into
trend and reverse trend.
• This calibration does not calibrate the load cells, the load cells are pre-calibrated.
To calibrate the scale system:
1. In the Maintenance Menu select the Calibrate Scale item then press and hold the Enter/Check button.
2. The display should present the following message:
“Do Not Touch Bed”. The message should be flashing.
3. Use the up and down arrow to select the proper weight (50lbs is the default).
4. Press the “Enter/Check” button when the display shows the proper weight.
5. The display should present the following message:
“Place Weight in Center”.
6. Place the weight in the center of the bed.
Service Information
