108 6086-009-001 REV A www.stryker.com
Head Section Assembly - 6500-002-023
Item Part No. Part Name Qty.
A 0004-168-000 Button Head Cap Screw 4
B 0004-591-000 Socket Head Cap Screw 4
C 0004-612-000 Button Head Cap Screw 8
D 0007-556-000 Truss Head Machine Screw 2
E 0008-030-000 Socket Head Shoulder Screw 2
F 0011-624-000 Washer 4
G 0014-002-000 Washer 2
H 0016-102-000 Nylock Hex Nut 4
J 0023-162-000 Delta Screw 4
K 0025-126-000 Rivet 2
L 0038-570-000 Compression Spring 2
M 6085-001-169 Head Section Nut 4
N 6085-001-170 Internal Bearing 4
P 6500-001-023 Head Trigger Assembly 1
R 6500-001-026 Head Section Lock Assy (page 110) 2
T 6500-001-086 Front Wheel 2
U 6500-001-087 Cap Bearing 2
V 6500-001-093 Safety Bar Lock Pin 2
W 6500-001-096 Head Section Release Link 2
Y 6500-001-220 Head Section Pivot Cross Tube 1
AA 6500-001-221 Cross Tube Clamp 2
AB 6500-001-280 Head Section Guard, Right 1
AC 6500-001-281 Head Section Guard, Left 1
AD 6500-001-322 Sliding Head Section Safety Bar 1
AE 6500-001-325 Safety Bar Torsion Spring, Left 1
AF 6500-001-326 Safety Bar Torsion Spring, Right 1
AG 6500-002-024 Telescoping Tube Assy (page 109) 1
AH 6500-002-106 Load Wheel Spacer 2
AJ 6500-002-107 Safety Bar Pivot, Right 1
AK 6500-002-108 Safety Bar Pivot, Left 1
AL 6500-002-109 Load Wheel Horn, Cover, Left 1
AM 6500-002-110 Load Wheel Horn, Cover, Right 1
AN 6500-002-120 Load Wheel Horn, Left 1
AP 6500-002-121 Load Wheel Horn, Right 1
AR 6500-002-114 Compression Limiter Sleeve 4
