www.stryker.com 6086-009-001 REV A 95
Outer Lift Tube Assembly, Litter Pivot, Left
6085-001-024 Rev B (Reference Only)
Item Part No. Part Name Qty.
A 0004-587-000 Button Head Cap Screw 2
B 0004-634-000 Button Head Cap Screw 4
C 0014-002-000 Washer 2
D 0015-051-000 Square Nut 6
E 0055-100-075 Riv Nut 4
F 0081-244-000 Flange Bearing 2
G 6085-001-054 Inner Base Leg Weldment 1
H 6085-001-095 Lower Frame Tube Bearing 1
J 6085-001-096 Slide Bearing 1
K 6500-001-125 Base Dead Stop 1
