Stryker Performance-PRO XT - Optional Dual Cot Retaining Post - 6085-034-000

Return To Table of Contents
90 6086-009-001 REV A www.stryker.com
Optional Dual Cot Retaining Post - 6085-034-000
Item Part No. Part Name Qty.
A 0004-160-000 Socket Head Cap Screw 4
B 0004-591-000 Socket Head Cap Screw 4
C 0004-503-000 Button Head Cap Screw 2
D 0016-003-000 Nylock Hex Nut 4
E 6060-004-043 Retaining Post Cap 2
F 6060-004-044 Post Tube 2
G 6080-090-108 Label, Lift Here 2
H 6500-001-189 Top Pin Bracket 2
J 6500-001-190 Bottom Pin Bracket 2
K 6500-001-302 Base Tube Protector 2
L 6085-001-057 Outer Base Tube Weldment 2
Rev C
Torque item C to
100-140 in-lb
Torque item C to
100-140 in-lb
