www.stryker.com 6086-009-001 REV B 9
Return To Table of Contents
SPECIFICATIONS
Safe Working Load
Note: Safe Working Load indicates the sum of
the patient mattress and accessory weight.
700 pounds 317,5 kg
Backrest Articulation/Shock Position 0° to 73° / +15°
Overall Length/Minimum Length/Width 80" / 64" / 23" 203,2 cm / 162,6 cm / 58,4 cm
Height
1
Position 1 13.8” 35,1 cm
Position 2 22” 55,9 cm
Position 3 25.8” 65,5 cm
Position 4 28.1” 71,4 cm
Position 5 31.9” 81 cm
Position 6 34.6” 87, 9 cm
Position 7 (LOW) 37.3 ” 94,7 cm
Position 8 (MID) 40” 101,6 cm
Position 9 (HIGH) 42.2” 107, 2 cm
Weight
2
89 lb 40,37 kg
Caster Diameter/Width 6" / 2" 15,2 cm / 5,1 cm
Minimum Operators Required for an Occupied Cot 2
Minimum Operators Required for an Unoccupied Cot 1
Recommended Fastener Systems Model 6370 or 6377 Floor Mount Type
Model 6371 Wall Mount Type
Maximum Loading Height
3
Up to 34" Up to 86,4 cm
Single Wheel Lock / Double Wheel Lock Optional
1
Height is measured from the bottom of the mattress at seat section to ground level.
2
Cot is weighed without mattress and restraints.
3
Load wheel height can be set between 27.25” (69,2 cm) and 34” (86,4).
Stryker reserves the right to change specifications without notice.
The Performance-PRO™ XT is designed to conform to the Federal Specification for the Star-of-Life Ambulance (KKK-A-1822).
The Performance-PRO™ XT is designed to be compatible with competitive cot fastener systems.
Patents pending.
The yellow and black color scheme is a proprietary trademark of Stryker Corporation.
