Cot Fastener Installation
WALL OF VEHICLE
ANTLER FLOOR
PLATES
14 5/8” (REF.)
OR DESIRED
POSITION FROM
WALL
REAR OF
AMBULANCE
(REF.)
COT CENTER LINE
COT PERIMETER
COT
HEAD
END
12 5/8”
2 5/8”
37 5/8”
14 15/16”
6 1/8”
24”
(REF.)
80” (REF.)
Figure 4: Installation Specifications - Floor Mount Fastener
Figure 5: Installation Specifications - Wall Mount Fastener
RAIL SUPPORT BRACKET
FLOOR PLATE
WALL OF VEHICLE
ANTLER FLOOR PLATES
14 5/8”
REAR OF
AMBULANCE
(REF.)
COT CENTER LINE
COT PERIMETER
COT
HEAD
END
14 15/16”
6 1/8”
24” (REF.)
80” (REF.)
1 1/8”
3 5/8”
4 5/16”
6 1/2”
37 3/8”
WALL MOUNTING BRACKET
FLOOR OF
VEHICLE
(32 cm)
(6,6 cm) (95,6 cm) (37,9 cm) (15,6 cm)
(61 cm)
(37,1 cm)
(37,1 cm)
(9,2 cm)
(94,9 cm)
(203 cm)
(16,5 cm)
(10,9 cm)
(37,9 cm) (15,6 cm)
(2,9 cm)
(61 cm)
(203 cm)
Note: These installation instructions are intended for cots that you will NOT use with Power-LOAD. For Model 6086
cots with the Power-LOAD option, see the Power-LOAD Operations/Maintenance Manual (6390-009-001) for installation
instructions.
