8.7.4.8 Schedule time
The schedule time pre-set allows to activate and deactivate the AC-Flex load relay in a daily base.
Restrictions can also be applied to avoid undesired activations. The parameters to setup this function
are:
Starting date
[secs from 01.01.1970]
Starting date of the scheduled daily activation-
deactivation. Before this date, the relay is disabled.
Starting time [secs from midnight]
Time of the day at which the relay is activated
Ending time [secs from midnight]
Time of the day at which the relay is deactivated
Selected weekday
Allowed weekdays for relay activation.
Recurrence weeks
Allow the relay to be daily activated each given week.
For example, with a value of 2 for this parameter, the
relay will be disabled every two weeks.
Range of recurrence selection
Selection of the ending of the recurrences:
No end date: the daily activation-deactivation
continue indefinitely
End after occurrence
End date
8.7.4.9 On-grid
Activates the relay when inverter is connected to a source (AC-Source). Typically used when extra
loads require to be connected only with external source.
8.7.4.10 Cmd-entry
AC-Flex load contact is controlled by a command entry available in the system. This entry is selected
by entering its index number (available in CMD-IN settings). Any command entry in the system can
be used to activate-deactivate the relay.
8.7.4.11 Errors and warnings
AC-Flex load relay is controlled according to the system alarms. Errors and/or warnings can be used
to activate the relay. The following possibilities are available:
Triggered by Errors
Triggered by Warnings
Triggered by errors and Warnings
8.7.4.12 Additional info regarding hysteresis operating mode
The following Pre-sets modes use a hysteresis-based logic to activate and deactivate the relay:
- Battery voltage
- Battery SOC
- Battery temperature
- Solar excess Ongrid
- Solar excess Offgrid
- On AC power
The hysteresis is given by 2 values configurable by the user: Activation threshold and deactivation
threshold. According to the numerical values set into the 2 thresholds, the hysteresis can follow 2
distinct behaviours (figure below). Having a value attributed to activation threshold higher than the
