1.30 5.14 IR Receiver
An infrared receiver is a component that receives infrared signals and can independently detect and output signals
compatible with TTL level. It is similar in size to a regular plastic-packaged transistor and is commonly used in
various applications such as infrared remote control and infrared transmission.
In this project, we will use an infrared receiver to detect signals from a remote control. When a button on the remote
control is pressed and the infrared receiver receives the corresponding signal, it can decode the signal to determine
which button was pressed. By decoding the received signal, we can identify the specific key or command associated
with it.
The infrared receiver allows us to incorporate remote control functionality into our project, enabling us to interact with
and control devices using infrared signals.
Required Components
In this project, we need the following components.
It’s definitely convenient to buy a whole kit, here’s the link:
Name ITEMS IN THIS KIT LINK
ESP32 Starter Kit 320+
You can also buy them separately from the links below.
COMPONENT INTRODUCTION PURCHASE LINK
ESP32 WROOM 32E
ESP32 Camera Extension -
Breadboard
Jumper Wires
IR Receiver
Available Pins
Here is a list of available pins on the ESP32 board for this project.
Available Pins IO13, IO12, IO14, IO27, IO26, IO25, IO15, IO0, IO5, IO18, IO19, IO21, IO22,
IO23
Schematic
